Diesel Engine Parts High Quality Remanufacture Fuel element Injector 4928260 4928260PX 4928260RX 4062569 4088725 4204584 4954434

Large Image : Diesel Engine Parts High Quality Remanufacture Fuel element Injector 4928260 4928260PX 4928260RX 4062569 4088725 4204584 4954434

Product Details:

Place of Origin:	USA
Brand Name:	CUMMINS
Certification:	ISO Contact: 86+ 19959162250
Model Number:	4928260

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$60-$100
Packaging Details:	Original Packing
Delivery Time:	3-5 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union,
Supply Ability:	1000

Contact Now

Detailed Product Description

OE NO:	CUMMINS INJECTOR	Product Name:	4928260
OE NO1:	4204584	Contact:	Contact: 86+ 19959162250
Warranty:	12 Months	Quality:	Brand New Genuine
SIZE:	Origional Standard	Type:	Auto Parts
AppliC-A-Tion:	Fuel Injection System	Material:	High Speed Steel
Highlight:	Cummins diesel injector remanufactured fuel element , Diesel engine parts fuel injector 4928260 , Cummins injector with warranty 4062569

Diesel Engine Parts High Quality Remanufacture Fuel element Injector 4928260 4928260PX 4928260RX 4062569 4088725 4204584 4954434

Product Description:

Number	4928260
OEM NO	4204584
AppliC-A-Tion	C-UMMINS INJECTOR
Payment Term	T/T, L/C, Western

Table 1: Basic Parameters

Parameter	Details
Part No.	4928260
Engine Series	C-ummins QSK15 / QSX15 Electronic Engines
Type	Electronic Unit Injector (EUI) / HPI Common Rail Injector
Structure	Integrated Solenoid, Plunger Boost, Top Outlet, Side Electrical Connector
Net Weight	2.15 kg
Dimensions	280mm × 65mm × 65mm
Material	Body: Forged Steel; Components: Hardened Alloy; Solenoid: High Permeability Stainless Steel

Table 2: Performance Specifications

Parameter	Details
Control	ECM Electronic Control (24V Solenoid), Closed-Loop Timing & Flow
Opening Pressure	280–300 bar (4060–4350 PSI)
Flow Rate	420–440 cc/min @ 100 PSI
Nozzle	9-Hole × 0.20mm, Spray Angle 140°
Fuel System	HPI (High Pressure Injection) System
Fuel Standard	China III/IV Diesel, 0# / -10# / -20#
Temp Range	-40℃ to +125℃
Seals	4× Fluororubber O-Rings, Copper Gasket, High-Temp Dust Seal
Electrical	2-Pin Deutsch Connector, IP67 Protection

Table 3: Application & Installation

Parameter	Details
Engine Fit	C-ummins QSK15 / QSX15 (15L Inline 6-Cyl, Turbocharged & Aftercooled)
Bore × Stroke	137mm × 169mm
Power Range	500–675 HP
Torque Range	2237–2779 N·m
Install Torque	Mounting Bolts: 75–85 N·m
Gasket	4024964 (Copper, Single-Use Only)
Install Notes	Deep Clean Fuel Passages, Replace All Seals, ECM Recalibration
Applications	Mining Trucks, Excavators, Drills, Marine, Gen-Sets

Table 4: Quality & Warranty

Parameter	Details
Grade	New Original / OEM Remanufactured (RX/R Suffix)
Factory Test	100% Flow, Pressure, Response, Atomization, Leakage & Durability Test
Warranty	New: 12 Months; Reman: 6–12 Months
Standard	C-ummins QSK Original, ISO 9001:2015
Packing	Single Box, Anti-Rust Oil, Shock-Proof Foam, Anti-Static Bag
MOQ	1 PC
Common Failures	Slow Response, Poor Atomization, Dripping, Black Smoke, Low Power, Rough Idle
Void Conditions	Bad Fuel, Contamination, Overpressure, Water Damage, Disassembly, Uncalibrated Programming

Why choose us?

1.The product has undergone a rigorous testing process, and we provide high-quality products.

2.We have our own professional forwarding agent: Fast delivery, serve good.

3.Our feedback: You always can get our feedback within 24 hours.

4.After sending, we will track the products for you once every two days, until you get the products.

PRODUCTS PICTURE:

Diesel Engine Parts High Quality Remanufacture Fuel element Injector 4928260 4928260PX 4928260RX 4062569 4088725 4204584 4954434 0

Diesel Engine Parts High Quality Remanufacture Fuel element Injector 4928260 4928260PX 4928260RX 4062569 4088725 4204584 4954434 3
