Common Rail Injector 1521978 1529790 4088725
Basic Properties
Place of Origin:
USA
Brand Name:
CUMMINS
Certification:
ISO Contact: 86+ 19959162250
Model Number:
4088725
Trading Properties
Minimum Order Quantity:
1
Price:
$60-$100
Payment Terms:
L/C, D/A, D/P, T/T, Western Union,
Supply Ability:
1000
Product Summary
Common Rail Injector 1521978 1529790 4088725 Product Description: Number 4088725 OEM NO 1529790 AppliC-A-Tion C-UMMINS INJECTOR Payment Term T/T, L/C, Western Table 1: Basic Parameters Parameter Details Part No. 4088725 Engine Series C-ummins QSK15 / QSX15 Electronic Engines Type Electronic Unit ...
Product Details
Highlight:
Cummins diesel common rail injector
,Cummins injector 1521978
,Diesel injector 4088725
OE NO:
CUMMINS INJECTOR
Product Name:
4088725
OE no1:
1529790
Contact:
Contact: 86+ 19959162250
Warranty:
12 Months
Quality:
Brand New Genuine
SIZE:
Origional Standard
Type:
Auto Parts
AppliC-A-Tion:
Fuel Injection System
Material:
High Speed Steel
Product Description
Common Rail Injector 1521978 1529790 4088725
Product Description:
| Number |
4088725 |
| OEM NO |
1529790 |
| AppliC-A-Tion | C-UMMINS INJECTOR |
| Payment Term | T/T, L/C, Western |
Table 1: Basic Parameters
| Parameter | Details |
| Part No. | 4088725 |
| Engine Series | C-ummins QSK15 / QSX15 Electronic Engines |
| Type | Electronic Unit Injector (EUI) / HPI Common Rail Injector |
| Structure | Integrated Solenoid, Plunger Boost, Top Outlet, Side Electrical Connector |
| Net Weight | 2.15 kg |
| Dimensions | 280mm × 65mm × 65mm |
| Material | Body: Forged Steel; Components: Hardened Alloy; Solenoid: High Permeability Stainless Steel |
Table 2: Performance Specifications
| Parameter | Details |
| Control | ECM Electronic Control (24V Solenoid), Closed-Loop Timing & Flow |
| Opening Pressure | 280–300 bar (4060–4350 PSI) |
| Flow Rate | 420–440 cc/min @ 100 PSI |
| Nozzle | 9-Hole × 0.20mm, Spray Angle 140° |
| Fuel System | HPI (High Pressure Injection) System |
| Fuel Standard | China III/IV Diesel, 0# / -10# / -20# |
| Temp Range | -40℃ to +125℃ |
| Seals | 4× Fluororubber O-Rings, Copper Gasket, High-Temp Dust Seal |
| Electrical | 2-Pin Deutsch Connector, IP67 Protection |
Table 3: Application & Installation
| Parameter | Details |
| Engine Fit | C-ummins QSK15 / QSX15 (15L Inline 6-Cyl, Turbocharged & Aftercooled) |
| Bore × Stroke | 137mm × 169mm |
| Power Range | 500–675 HP |
| Torque Range | 2237–2779 N·m |
| Install Torque | Mounting Bolts: 75–85 N·m |
| Gasket | 4024964 (Copper, Single-Use Only) |
| Install Notes | Deep Clean Fuel Passages, Replace All Seals, ECM Recalibration |
| Applications | Mining Trucks, Excavators, Drills, Marine, Gen-Sets |
Table 4: Quality & Warranty
| Parameter | Details |
| Grade | New Original / OEM Remanufactured (RX/R Suffix) |
| Factory Test | 100% Flow, Pressure, Response, Atomization, Leakage & Durability Test |
| Warranty | New: 12 Months; Reman: 6–12 Months |
| Standard | C-ummins QSK Original, ISO 9001:2015 |
| Packing | Single Box, Anti-Rust Oil, Shock-Proof Foam, Anti-Static Bag |
| MOQ | 1 PC |
| Common Failures | Slow Response, Poor Atomization, Dripping, Black Smoke, Low Power, Rough Idle |
| Void Conditions | Bad Fuel, Contamination, Overpressure, Water Damage, Disassembly, Uncalibrated Programming |
