High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine

All Products
CATERPILLAR Diesel Fuel Injectors (15084)
BOSCH Diesel Fuel Injectors (2426)
DENSO Diesel Injector (4282)
Diesel Fuel Pumps (2554)
CUMMINS Diesel Injector (5494)
VOLVO Diesel Injector (2715)
TOYOTA Diesel Fuel Injectors (985)
DELPHI Diesel Injector (896)
Diesel Injector Control Valve (911)
KOMATSU Fuel Injectors (47)
ISUZU Diesel Injector (197)
Urea PUMP (1)
Diesel Test Bench (3)
PERKINS Fuel injector (436)
Best Products
Fuel Injector Cum-mins In Stock QSK19 Common Rail Injector Y431K05417 Y431K05248 4964171

Fuel Injector Cum-mins In Stock QSK19 Common Rail Injector Y431K05417 Y431K05248 4964171

Fuel Injector Cum-mins In Stock NT855 NTA855 Common Rail Injector 4914328 4914308 4914325

Fuel Injector Cum-mins In Stock NT855 NTA855 Common Rail Injector 4914328 4914308 4914325

Common Rail Diesel Fuel N14 Injector 3080766 3070118 3070113 For Cummins

Common Rail Diesel Fuel N14 Injector 3080766 3070118 3070113 For Cummins

I'm Online Chat Now

High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine

High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine
High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine

Large Image :  High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine

Product Details:
Place of Origin: USA
Brand Name: CUMMINS
Certification: ISO Contact: 86+ 19959162250
Model Number: 570016
Payment & Shipping Terms:
Minimum Order Quantity: 1
Price: $60-$100
Packaging Details: Original Packing
Delivery Time: 3-5 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union,
Supply Ability: 1000
Contact Now
Detailed Product Description
OE NO: CUMMINS INJECTOR Product Name: 570016
OE NO1: 1521978 Contact: Contact: 86+ 19959162250
Warranty: 12 Months Quality: Brand New Genuine
SIZE: Origional Standard Type: Auto Parts
AppliC-A-Tion: Fuel Injection System Material: High Speed Steel
Highlight:

Cummins diesel fuel injector 1521978

,

Scania ISX diesel injector 4076963

,

DT12 engine fuel injector 570016

High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine

Product Description:
Number

570016
OEM NO

1521978
AppliC-A-Tion  C-UMMINS INJECTOR
Payment Term T/T, L/C, Western





Table 1: Basic Parameters

Parameter Details
Part No. 570016
Engine Series C-ummins QSK15 / QSX15 Electronic Engines
Type Electronic Unit Injector (EUI) / HPI Common Rail Injector
Structure Integrated Solenoid, Plunger Boost, Top Outlet, Side Electrical Connector
Net Weight 2.15 kg
Dimensions 280mm × 65mm × 65mm
Material Body: Forged Steel; Components: Hardened Alloy; Solenoid: High Permeability Stainless Steel



Table 2: Performance Specifications

Parameter Details
Control ECM Electronic Control (24V Solenoid), Closed-Loop Timing & Flow
Opening Pressure 280–300 bar (4060–4350 PSI)
Flow Rate 420–440 cc/min @ 100 PSI
Nozzle 9-Hole × 0.20mm, Spray Angle 140°
Fuel System HPI (High Pressure Injection) System
Fuel Standard China III/IV Diesel, 0# / -10# / -20#
Temp Range -40℃ to +125℃
Seals 4× Fluororubber O-Rings, Copper Gasket, High-Temp Dust Seal
Electrical 2-Pin Deutsch Connector, IP67 Protection



Table 3: Application & Installation

Parameter Details
Engine Fit C-ummins QSK15 / QSX15 (15L Inline 6-Cyl, Turbocharged & Aftercooled)
Bore × Stroke 137mm × 169mm
Power Range 500–675 HP
Torque Range 2237–2779 N·m
Install Torque Mounting Bolts: 75–85 N·m
Gasket 4024964 (Copper, Single-Use Only)
Install Notes Deep Clean Fuel Passages, Replace All Seals, ECM Recalibration
Applications Mining Trucks, Excavators, Drills, Marine, Gen-Sets



Table 4: Quality & Warranty

Parameter Details
Grade New Original / OEM Remanufactured (RX/R Suffix)
Factory Test 100% Flow, Pressure, Response, Atomization, Leakage & Durability Test
Warranty New: 12 Months; Reman: 6–12 Months
Standard C-ummins QSK Original, ISO 9001:2015
Packing Single Box, Anti-Rust Oil, Shock-Proof Foam, Anti-Static Bag
MOQ 1 PC
Common Failures Slow Response, Poor Atomization, Dripping, Black Smoke, Low Power, Rough Idle
Void Conditions Bad Fuel, Contamination, Overpressure, Water Damage, Disassembly, Uncalibrated Programming



Why choose us?

1.Super Value - Our rich experience help you increase profit on cost advantage.

2.We have our own professional forwarding agent: Fast delivery, serve good.

3.Our feedback: You always can get our feedback within 24 hours.

4.After sending, we will track the products for you once every two days, until you get the products.


PRODUCTS PICTURE:

High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine 0High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine 1High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine 2

High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine 3High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine 4

High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine 5
High Quality Diesel Fuel Injector 1521978 4076963 4903028 570016 for C-UMMINS SCANIA ISX DT12 02HPI QSX15 Engine 6
