NT855 3054233 3071497 Marine Engine Parts Diesel Engine Fuel Injector
Basic Properties
Place of Origin:
USA
Brand Name:
CUMMINS
Certification:
ISO Contact: 86+ 19959162250
Model Number:
3054233
Trading Properties
Minimum Order Quantity:
1
Price:
$60-$100
Payment Terms:
L/C, D/A, D/P, T/T, Western Union,
Supply Ability:
1000
Product Summary
NT855 3054233 3071497 Marine Engine Parts Diesel Engine Fuel Injector Product Description: Number 3054233 OEM NO 3071497 AppliC-A-Tion C-UMMINS INJECTOR Payment Term T/T, L/C, Western Table 1: Basic Parameters Parameter Details Part No. 3054233 Engine Series C-ummins NT855 Series (PT Fuel System ...
Product Details
Highlight:
Cummins diesel fuel injector
,NT855 marine engine injector
,diesel engine injector with warranty
OE NO:
CUMMINS INJECTOR
Product Name:
3054233
OE no1:
3071497
Contact:
Contact: 86+ 19959162250
Warranty:
12 Months
Quality:
Brand New Genuine
SIZE:
Origional Standard
Type:
Auto Parts
AppliC-A-Tion:
Fuel Injection System
Material:
High Speed Steel
Product Description
NT855 3054233 3071497 Marine Engine Parts Diesel Engine Fuel Injector
Product Description:
| Number |
3054233 |
| OEM NO |
3071497 |
| AppliC-A-Tion | C-UMMINS INJECTOR |
| Payment Term | T/T, L/C, Western |
Table 1: Basic Parameters
| Parameter | Details |
| Part No. | 3054233 |
| Engine Series | C-ummins NT855 Series (PT Fuel System Mechanical Engines) |
| Type | Mechanical PT Injector (PTD Type, No STC) |
| Structure | Plunger-type, Cam-driven, Cylinder, Flangeless |
| Net Weight | 1.55 kg |
| Dimensions | 205mm × 58mm × 58mm |
| Material | Body: Alloy Cast Iron; Parts: Hardened High-Speed Steel |
Table 2: Performance Specifications
| Parameter | Details |
| Fuel System | PT (Pressure-Time) Low-Pressure System |
| Opening Pressure | 135–145 bar (1960–2100 PSI) |
| Flow Rate | 320–335 cc/min @ 100 PSI |
| Nozzle | 8-Hole × 0.24mm, Spray Angle 155° |
| Timing Control | Purely Mechanical, Direct Cam Drive |
| Fuel Standard | China I/II Diesel, 0# / -10# / -20# |
| Temp Range | -30℃ to +115℃ |
| Seals | 2× Fluororubber O-Rings, Copper Gasket |
| Actuation | Camshaft, Tappet & Pushrod Mechanism |
Table 3: Application & Installation
| Parameter | Details |
| Engine Fit | C-ummins NT855 (14.0L Inline 6-Cyl, Turbocharged & Aftercooled) |
| Bore × Stroke | 139.7mm × 152.4mm |
| Power Range | 350–450 HP |
| Torque Range | 1650–1950 N·m |
| Install Torque | Retaining Nut: 60–65 N·m |
| Gasket | 3077265 (Copper, Single-Use Only) |
| Install Notes | Clean Fuel Passages, Replace All Seals, Calibrate Plunger Lift |
| Applications | Heavy Trucks, Construction, Mining, Marine, Gen-Sets |
Table 4: Quality & Warranty
| Parameter | Details |
| Grade | New Original / OEM Remanufactured |
| Factory Test | 100% Flow, Pressure, Leakage & Atomization Test |
| Warranty | New: 12 Months; Reman: 6 Months |
| Standard | C-ummins Original, ISO 9001:2015 |
| Packing | Single Box, Anti-Rust Oil, Shock-Proof Foam |
| MOQ | 1 PC |
| Common Failures | Poor Atomization, Dripping, Hard Start, Black Smoke, Low Power |
| Void Conditions | Contaminated Fuel, Overpressure, Unauthorized Disassembly |
