C12 Injector Assembly 166-0149 212-3460 212-3462 212-3463 212-3468 10R-1264 10R-0961 10R-0967 for CAT Engine C12 Injector

Large Image : C12 Injector Assembly 166-0149 212-3460 212-3462 212-3463 212-3468 10R-1264 10R-0961 10R-0967 for CAT Engine C12 Injector

Product Details:

Place of Origin:	USA
Brand Name:	C-A-TERPILLA
Certification:	Contact: 86+ 19959162250
Model Number:	10R-0967

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$400-$550
Packaging Details:	Original Packing
Delivery Time:	3-5 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, , Western Union
Supply Ability:	1000

Contact Now

Detailed Product Description

Product Name:	C-A-Terpillar Injector	OE NO:	10R-0967
OE NO1:	212-3462	Warranty:	12 Months
Contact:	86+ 19959162250	Quality:	Brand New Genuine
Car Model:	C-A-T ENGINE	AppliC-A-Tion:	Fuel Injection System
Material:	High Speed Steel	Type:	Trck
SIZE:	Origional Standard
Highlight:	C12 injector assembly for CAT engine , CATERPILLAR diesel fuel injector 166-0149 , CAT C12 injector 10R-1264 replacement

Parts	10R-0967
OEM NO	212-3462
Powerplant	nozzle
Payment term	T/T,Western Union

Basic Information Table

Item	Detailed Specifications
Product Model	10R-0967
Applicable Engine	C-aterpillar C10, C12 Series Diesel Engines
Product Type	High-Pressure Common Rail Electronically Controlled Injector (HEUI)
Product Status	New Part / Remanufactured Part (REMAN)
Brand	C-aterpillar
Weight	Approx. 1.8kg (3.97lbs)
Core Components	Solenoid Valve, Injector Nozzle, Plunger Pair, Spring Assembly, Seals, Control Valve Core, Filter Screen
Production Standard	C-aterpillar Original OEM Standard, Compliant with ISO/TS 16949 Quality System Certification, Adapted to Heavy-Duty Working Conditions

Core Technical Parameters Table

Parameter Category	Specific Value	Remarks
Injection System	High-Pressure Common Rail Type	Working Pressure: 2400-3400bar, Precisely Matching the Power Output Characteristics of C10/C12 Engines
Control Method	Electronically Controlled (FIS Independent Solenoid Valve Drive)	Response Time ≤ 0.65ms, High Injection Precision, Effectively Optimizing Fuel Economy and Improving Engine Power Response
Number of Nozzle Holes	Multi-hole Type (Standard 8 Holes, Precise Aperture Adaptation)	Uniform Atomization Effect, Full Fuel Combustion, Reduced Exhaust Emissions, Compliant with China Stage III and EU Stage IIIB Emission Standards
Flow Characteristics	Rated Flow Matches C10/C12 Engine Calibration Value	170-200L/min (Refer to C-aterpillar Original Parameter Standard for C10/C12 Series Engines)
Working Voltage	24V DC	Adapted to Heavy Construction Machinery Electrical System, Strong Anti-Interference Ability, Excellent Voltage Stability in High and Low Temperature Environments
Needle Valve Opening Pressure	Approx. 310-350bar	Ensures Atomization Quality, Reduces Carbon Deposits, and Extends the Service Life of Engines and Injectors
Protection Level	IP67	Dustproof and Waterproof, Adapted to Harsh Working Environments such as Mines, Construction Sites and Ports, Not Easily Affected by External Impurities
Working Temperature	-40℃ to +140℃	Adapts to Different Global Climatic Environments and Can Work Stably Under High-Temperature Heavy-Duty and Low-Temperature Startup Conditions
Material	High-Strength Alloy Steel, Wear-Resistant Ceramic Nozzle, High-Temperature Resistant Fluororubber Seals	Excellent Compression Resistance, Corrosion Resistance and Wear Resistance, Adapted to the Heavy-Duty Working Characteristics of C10/C12 Engines

Applicable Models Table

Equipment Type	Specific Models	Engine Configuration
Excavators	CAT 330C, 336C, 345C, 349C, 365C	C10/C12 ACERT™ Inline 6-Cylinder Diesel Engine, Strong Power, Adapted to Heavy-Duty Excavation Operations
Wheel Loaders	CAT 966G, 972G, 980G, 988G, 990G	C10/C12 Industrial-Grade Diesel Engine, Large Torque, Adapted to High-Intensity Loading and Unloading Operation Requirements
Bulldozers	CAT D8R, D9R, D10R, D11R	C12 Non-Road China Stage III / EU Stage IIIB Emission Engine, Abundant Power, Adapted to Mine and Infrastructure Earthmoving Operations
Other Equipment	Heavy-Duty Trucks, Road Rollers, Pavers, Mine Drills, High-Power Generator Sets	Various Heavy Construction Machinery and Power Equipment Equipped with C10/C12 Series Engines
Emission Standard	China Stage III, EU Stage IIIB, EPA Tier 3/4	Meets Mainstream Global Emission Regulations and Adapts to Construction and Usage Requirements in Different Regions

Installation and After-Sales Parameters Table

Item	Detailed Description
Installation Torque	Injector Fixing Bolt: 70±5 Nm; Solenoid Valve Connector: 40±5 Nm (Strictly Follow C-aterpillar Original Installation Standard)
Installation Requirements	Must use C-aterpillar original gaskets; Thoroughly clean the cylinder head oil passage, mounting surface and injector interface before installation; Do not strike or collide with the injector body and nozzle
Warranty Period	New Part: 12 Months or 10000 Working Hours (whichever comes first); Remanufactured Part: 6-12 Months (Depending on Supplier Standard)
Used Part Recycling	Used Part Recycling Deposit: Approx. 260 USD/Unit; Full Deposit Refundable if Used Part is Returned within 45 Days, and the Used Part Must Be Free of Severe Damage and Rust
