Common Rail diesel Injector for C-A-T C9.3 ENGINE 364-8024 367-4293 382-0709 392-9046 3648024 3674293 3820709 3929046

Large Image : Common Rail diesel Injector for C-A-T C9.3 ENGINE 364-8024 367-4293 382-0709 392-9046 3648024 3674293 3820709 3929046

Product Details:

Place of Origin:	USA
Brand Name:	C-A-TERPILLA
Certification:	Contact: 86+ 19959162250
Model Number:	392-9046

Payment & Shipping Terms:

Minimum Order Quantity:	1
Price:	$400-$550
Packaging Details:	Original Packing
Delivery Time:	3-5 work days
Payment Terms:	L/C, D/A, D/P, T/T, Western Union, , Western Union
Supply Ability:	1000

Contact Now

Detailed Product Description

Product Name:	C-A-Terpillar Injector	OE NO:	392-9046
OE NO1:	367-4293	Warranty:	12 Months
Contact:	86+ 19959162250	Quality:	Brand New Genuine
Car Model:	C-A-T ENGINE	AppliC-A-Tion:	Fuel Injection System
Material:	High Speed Steel	Type:	Trck
SIZE:	Origional Standard
Highlight:	Caterpillar C9.3 diesel injector , Common Rail injector for CAT engine , CAT 364-8024 fuel injector

Parts	392-9046
OEM NO	367-4293
Powerplant	nozzle
Payment term	T/T,Western Union

Basic Information Table

Item	Detailed Specifications
Product Model	392-9046
Applicable Engine	C-aterpillar C9.3 Series Diesel Engine
Product Type	High-Pressure Common Rail Electronically Controlled Injector (HEUI)
Product Status	New Part / Remanufactured Part (REMAN)
Brand	C-aterpillar
Weight	Approx. 1.6kg (3.53lbs)
Core Components	Solenoid Valve, Injector Nozzle, Plunger, Spring Assembly, Seals, Control Valve Core
Production Standard	C-aterpillar Original OEM Standard, Compliant with ISO/TS 16949 Quality System Certification

Core Technical Parameters Table

Parameter Category	Specific Value	Remarks
Injection System	High-Pressure Common Rail Type	Working Pressure: 2500-3500bar, Adapted to C9.3 Engine Power Output Requirements
Control Method	Electronically Controlled (FIS Independent Solenoid Valve Drive)	Response Time ≤ 0.7ms, High Injection Precision, Effectively Reducing Fuel Consumption and Improving Power
Number of Nozzle Holes	Multi-hole Type (Standard 8 Holes)	Optimized Atomization Effect, Full Fuel Combustion, Reduced Exhaust Emissions, Compliant with Environmental Standards
Flow Characteristics	Rated Flow Matches C9.3 Engine Calibration Value	160-190L/min (Refer to C9.3 Series Engine Parameter Standard)
Working Voltage	24V DC	Adapted to Heavy Construction Machinery Electrical System, High Stability and Outstanding Anti-Interference Ability
Needle Valve Opening Pressure	Approx. 300-340bar	Ensures Atomization Quality, Improves Combustion Efficiency, and Reduces Carbon Deposits
Protection Level	IP67	Dustproof and Waterproof, Adapted to Harsh Working Environments such as Mines and Construction Sites, Not Easy to Be Damaged
Working Temperature	-40℃ to +135℃	Adapts to Different Global Climatic Environments and Can Work Stably Under High and Low Temperature Conditions
Material	High-Strength Alloy Steel, Wear-Resistant Ceramics, High-Temperature Resistant Sealing Materials	Excellent Compression Resistance, Corrosion Resistance and Wear Resistance, Extending Product Service Life

Applicable Models Table

Equipment Type	Specific Models	Engine Configuration
Excavators	CAT 320D2, 323D2, 326D2, 330D2, 336D2	C9.3 ACERT™ Inline 6-Cylinder Diesel Engine with Strong Power
Wheel Loaders	CAT 950M, 962M, 972M, 980M, 988M	C9.3 Industrial-Grade Diesel Engine, Adapted to Heavy-Duty Operation Requirements
Bulldozers	CAT D6N, D7N, D8N, D9N	C9.3 Non-Road China Stage III / EU Stage IIIB/IV Emission Engine, Environmentally Compliant
Other Equipment	Road Rollers, Pavers, Mine Drills, Forklifts, Generator Sets	Various Heavy Construction Machinery Equipped with C9.3 Series Engines
Emission Standard	China Stage III, EU Stage IIIB/IV, EPA Tier 4 Final	Meets Mainstream Global Emission Regulations and Adapts to Usage Requirements in Different Regions

Installation and After-Sales Parameters Table

Item	Detailed Description
Installation Torque	Injector Fixing Bolt: 65±5 Nm; Solenoid Valve Connector: 38±5 Nm (Refer to C-aterpillar Original Standard)
Installation Requirements	Must use original gaskets; Thoroughly clean the cylinder head oil passage and mounting surface before installation; Do not strike the injector body and nozzle
Warranty Period	New Part: 12 Months or 10000 Working Hours (whichever comes first); Remanufactured Part: 6-12 Months (Depending on Supplier Standard)
Used Part Recycling	Used Part Recycling Deposit: Approx. 240 USD/Unit; Full Deposit Refundable if Used Part is Returned within 45 Days
Replacement Cycle	Normal Working Conditions: 12000-15000 Hours; Harsh Working Conditions: 6000-8000 Hours
Fault Judgment	Black Smoke Emission, Lack of Power, Sudden Increase in Fuel Consumption, Unstable Idle Speed, Difficult Startup, Engine Vibration, Abnormal Injection
Packaging Specification	Independent Shockproof Carton Packaging, Including Product Certificate of Conformity, Installation Manual, and Gaskets (Accessories)
Applicable Scenarios	Heavy Construction Machinery Fields such as Mine Mining, Construction, Agricultural Operations, Port Loading and Unloading, and Oilfield Exploitation
